AS400 IBM 9406 LAN WAN, #5721 PCI-X 10Gbps Ethernet-SR IOA

Brand: IBM AS400 iSeries
Product Code: 5721-9406
<p><font face=&#34;&#34;>#5721 PCI-X 10Gbps Ethernet-SR IOA</font></p> <p><font face=&#34;&#34;>Provides 10Gbps Ethernet server connection using a PCI-X DDR IOA. Supports distances of up to 33m using 62.5um multimode fiber or 300m using 50um multimode fiber with 2000MHz km minimum model bandwidth at 850nm. Adapter connector type is LC. </font></p><p class=&#34;&#34;><font face=&#34;&#34;>The 10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter is designed to provide a PCI-X based server connection. The adapter conforms to the IEEE 802.3ae 10 Gigabit Ethernet standard and supports jumbo frames.</font></p> <div class=&#34;&#34;><p><font face=&#34;&#34;>The 10 Gb Ethernet-SR PCI-X supports the following distances:</font></p><ul><li><font face=&#34;&#34;>Up to 33m using 62.5 um multimode fiber with 200 MHz*km minimum modal bandwidth at 850 nm</font></li><li><font face=&#34;&#34;>Up to 300m using 50 um multimode fiber with 2000 MHz*km minimum modal bandwidth at 850 nm</font></li></ul> </div> <p class=&#34;&#34;><font face=&#34;&#34;>The adapter is designed to run in standard PCI-X v2.0 and PCI-X v1.0a compliant systems with 64-bit PCI-X BusMaster slots at 133 Mode 1 or Mode 2. The adapter draws power from the PCI-X 3.3 V supplies and is keyed to fit only into a 3.3 V slot. The adapter supports 1M x 8 bit boot FLASH ROM and has a 240 KB on-chip TX packet buffer and a 32 MB on-chip RX packet buffer.</font></p> <div class=&#34;&#34;><p><font face=&#34;&#34;>The FRU part numbers for the adapter are:</font></p><ul><li><font face=&#34;&#34;>Adapter, 03N4590 (<span class=&#34;&#34;>Designed to comply with RoHS requirement.</span>)</font></li><li><font face=&#34;&#34;>Wrap plug, 11P3847</font></li></ul> </div> <p><font face=&#34;&#34;>The adapter provides the following features:<br /></font></p><ul><li><font face=&#34;&#34;>Single-slot, short form factor, 6.6 by 4.2 inch, half-length PCI cards</font></li><li><font face=&#34;&#34;>64-bit Direct Bus Mastering on the PCI-X bus</font></li><li><font face=&#34;&#34;>Dual Address Cycle for access to 64-bit addresses</font></li><li><font face=&#34;&#34;>PCI-X split transactions</font></li><li><font face=&#34;&#34;>DMA engine for movement of command, status, and network data across PCI-X</font></li><li><font face=&#34;&#34;>240 KB on-chip TX packet buffer</font></li><li><font face=&#34;&#34;>32 MB on-chip RX packet buffer</font></li><li><font face=&#34;&#34;>1 MB Boot Flash ROM</font></li><li><font face=&#34;&#34;>Jumbo frames (9 KB)</font></li><li><font face=&#34;&#34;>Interrupts coalescing</font></li><li><font face=&#34;&#34;>802.1q VLAN tagging and stripping <span class=&#34;&#34;>(<span class=&#34;&#34;>IBM&reg; System i&reg;</span> models do not support VLANs)</span></font></li><li><font face=&#34;&#34;>Conforms to IEEE 802.3ae 10 Gigabit Ethernet standard</font></li></ul> <div id=&#34;&#34; class=&#34;&#34;><p class=&#34;&#34;><font face=&#34;&#34;><strong>Operating system or partition requirements</strong></font></p><ul><li><font face=&#34;&#34;><span class=&#34;&#34;>AIX 5L&trade; Version 5.3 with the 5300-04 Technology Level</span></font></li><li><font face=&#34;&#34;><span class=&#34;&#34;>AIX 5L Version 5.2 with the 5200-08 Technology Level</span></font></li><li><font face=&#34;&#34;><span class=&#34;&#34;>Red Hat Enterprise Linux&reg; version 4</span> U2</font></li><li><font face=&#34;&#34;><span class=&#34;&#34;>SUSE Linux Enterprise Server 9</span> SP3</font></li></ul> </div><p><font face=&#34;&#34;>#5721 does not support SNA. #5721 is a smart IOA and operates only in IOP-less mode, even when used by i5/OS. </font></p><ul><li><p><font face=&#34;&#34;>Attributes provided: 10Gbps Ethernet connection </font></p></li><li><p><font face=&#34;&#34;>Attributes required: Available PCI-X slot. However, for improved bandwidth plug into PCI-X 2.0 DDR slot </font></p></li><li><p><font face=&#34;&#34;>For 9409-M50: (#5721) </font></p><ul><li><p><font face=&#34;&#34;>Minimum required: 0 </font></p></li><li><p><font face=&#34;&#34;>Maximum allowed: 12 (Initial order maximum: 12) </font></p></li><li><p><font face=&#34;&#34;>OS level required: i5/OS V5R4 with V5R4M5 Machine Code, or later, AIX 5L for POWER V5.2 for IBM eServer, or later, Red Hat Enterprise Linux AS for POWER Version 4, or later, SUSE Linux Enterprise Server 9 for POWER, or later </font></p></li><li><p><font face=&#34;&#34;>Initial Order/MES/Both/Supported: Both </font></p></li><li><p><font face=&#34;&#34;>CSU: Yes </font></p></li></ul></li></ul><p><font face=&#34;&#34;><strong>Supported on the following models: </strong>515, 520, 525, 550, 570, 595, M15, M25, M50, MMA</font></p><p><strong><font face=&#34;&#34;>And on the following machine types:</font></strong><font face=&#34;&#34;> 9405, 9406, 9407, 9408, 9409, 9411</font> <br /></p>
